Conductive low-e glass




TEK FTO glass is a conductive glass, with different resistance and VLT.


we have TEK 10,TEK15,TEK35,TEK70 with thickness 2.1mm, 3.2mm,4mm, 6mm, 8mm,10mm.


The normal size of the TEK glass is 1830x2440mm, 1830x2200mm, 2140x3300mm, 2134x2200mm.



The size can be customized following client's request.


Collect
Product introduction


We are in  Zibo City Shandong Province China, the conductive low-e glass with different thickness , glass used for photoelectric glass,automotive glass, refrigerator, oven ETC.





We have been exporting conductive low-e glass to many counties .


below is the specifications of conductive low-e glass:



Performance Data:


Item No.          TEK10         TEK15         TEK35         TEK70       TEK250
Thickness   4mm 3.2mm    4mm 3.2mm   4mm 3.2mm   4mm 3.2mm    4mm 3.2mm
Visible Light Transmittance         ≥82%       >83%     ≥83%       >83%      >83%
Coating film  Reflectance         ≤11%       <12%     <12%       <12%      <12%
Haze of film         ≤1.7%        ≤1%     <1%        ≤1%       ≤1%
Resistance(before glass tempered        8.0-9.5Ω       12-14Ω     34-38Ω       60-68Ω      260-320Ω
Resistance(after glass tempered)         9.0-10Ω      12-14Ω      38-40Ω       64-72Ω      252-300Ω
Radiance            <0.13       <0.15      <0.35         <0.45         <0.6





The resistance can be adjusted following client's request due to different project data needed.


Normal size of the conductive low-e glass;


1830x2440mm, 1830x2200mm, 2140x3300mm, 2134x2200mm.


and others special size can be customized.
